Pure / Ultra pure water manufacturing device, Scientific equipment, Physical and chemical equipment
Dimensions
400(W) x 492(D) x 517(H)mm
<tab title="Features">
16X2 blue backlight LCD
Can indicating error messages
Equipped U.W water quality sensor : real-time display
Estimate filter life : display run time & remain life (as %)
Replacement warning and screen display : when water quality falls lower than standard
Display filter error : filter packโs wrong position or wrong pack type
Easy replacement : U.W filter is designed as Pack type (Design registered on Korea Gov.)
Openable front door for easy maintenance
Item# | MDM-0124 |
Model | Dream Mega |
Flow Rate | Max. 45โ/hr. |
Water quality display | Ultra Pure Water (U.W) : 0 ~ 18.2Mฮฉ.cm |
Display | 16ร2 characters backlight LCD digital display |
Standard Filter | Mega U.W Pack, 0.2ยตm Final filter |
Option Filterโs | 254/185nm UV Lamp , 0.05ยตm UF filter |
Functions | System initializing : Automatic self test when starting Auto recycles for 10 sec with starting Self protect functions : 1. Auto stop and restart by level sensor 2. Auto stop and restart function by filter wrong installation or pack type Mode key function : 1. U.W Purity remain(%) 2. Buzzer off Check key function : Warning when filter purity falls lower than standard Filter replacement function โFilter replaceโ indication |
Input water conditions | Input pressure 1~3kgf/cm2, Input temperature 4 ~ 35ยฐC |
Dimensions | 315(W) ร 492(D) ร 517(H)mm |
Power | 230Vac, 50/60Hz, 60W |
Type | Simple | TOC | Cella | Finesta |
---|---|---|---|---|
Feature | ||||
0.2ยตm Final Filter | standard | standard | standard | standard |
254/185nm UV Lamp | โ | standard | โ | standard |
0.05ยตm UF filter | โ | โ | standard | standard |
Water Quality | ||||
TOC(ppb) | 5 ~ 10 | 1 ~ 5 | 5 ~ 10 | 1 ~ 5 |
Pyrogens | โ | โ | < 0.001Eu/mโ | < 0.001Eu/mโ |
Particle (0.2ยตm) | < 1/mโ | < 1/mโ | < 1/mโ | < 1/mโ |
Bacteria | < 1cfu/mโ | < 1cfu/mโ | < 1cfu/mโ | < 1cfu/mโ |
