KR1000
Model Name
KR1000
Series
Rotary Joint
Data
ROTARY JOINT
Manufacturer information
provider logo
KWANG JIN(KJC)

Rotary joint, Swivel joint, Heating cover, Ceramic board, Rock wool board

Problem with product info?
Update request
Manufacturer
KWANG JIN(KJC)
Brand
-
SKU
59165
Product Name
-
Model Name
KR1000
Size
-
Weight
-
Product Details
Size Range 15A~80A (1/2"~3")
Max. Pressure 15kg/㎠ (210PSI)
Max. Temperature 180℃ (360℉)
Max. Rotation Speed
   15A~40A
   (1/2"~1-1/2")
300RPM
   50A~80A(2"~3") 150RPM
Media Steam , Hot Oil , Water



-Low Friction
-High speed operation enabled at high temperature & pressure media
-Bellows in side,enables switching between cooling & heating  operation

KWANG JIN(KJC)
Rotary joint, Swivel joint, Heating cover, Ceramic board, Rock wool board
In 1986, it succeeded in localizing joint parts for the first time in Korea, and is continuously developing and supplying various parts in recognition of its quality from the steel industry to the secondary battery industry. In addition, we are accelerating the expansion of overseas markets in North and Central America, Europe, Asia, and the Middle East based on our proven technology in domestic industrial sites. KWANGJIN CORPORATION will secure competitiveness through continuous technology development and quality improvement and provide products and services that meet various needs of customers.
